Fiber laser F10MW1 in workstation / housing

Laser safety class 1

Construction Year 06/2017.

IPG Laser Beam

MOPA Laser

Power: 10 watts

Brand: KOLLTRONIC

Made in Germany

Laser medium: diode-pumped fiber laser, Yb

Wavelength: 1064 nm

Marking field: 110 x 110 mm

Cooling: air

Combined seat and stand workplace.

Front door with laser safty protection glass = view of the workpiece.

Work room is illuminated.

Z-axis motorized.

Quick positioning of the workpieces on a special magnetic worktop with hole pattern.

Ex works price.

Software inclusive.

Installation and trainig as option available.

Option: expandable with rotary axis.

Typical Applications

- marking

- engraving

- etching

- stripping

- cutting

Pictures may differ.

Fiber laser F10MMT on machine table
Laser safety class 4

Construction Year 06/2017.
IPG Laser Beam
MOPA Laser
Power: 10 watts
Brand: KOLLTRONIC
Made in Germany
Laser medium: diode-pumped fiber laser, Yb
Wavelength: 1064 nm
Marking field: 110 x 110 mm
Bivacq7qwc
Cooling: air

Combined seat and stand workplace.
Z-axis motorized.
Quick positioning of the workpieces on a special magnetic worktop with hole pattern.

Ex works price.
Software inclusive.
Installation and trainig as option available.
Option: expandable with rotary axis.


Typical Applications
- marking
- engraving
- etching
- stripping
- cutting

Pictures may differ.

SK LASER  KOLLTRONIC®

Type: F20CW1 - F20Compact with Workstation 1
Diode-pumped Ytterbium fiber - laser

Best for marking on metall and plastic.
Output power 20 Watt
COMPUTER
SOFTWARE KOLLTRONIC®
KOLLTRONIC® WORKSTATION
in Laser safety class 1 for Fibre-Laser F10 - F50
Made in Germany

Demo machine    23.900,- Euro net ex works price
